Vertica Pro DUO Charging Station - Manual Configurator
11.542,27 zł netto
This is the new generation of Enelion commercial EV charging stations — one of the few chargers in Europe equipped with a color OLED touchscreen with the ability to display dynamic QR codes for payments. Its slim, column-like design with two charging points makes it ideal for car parks, shopping centers, hotels, and residential areas.
The station is available in two configurations — with a Type 2 socket or a Type 2 cable — choose the appropriate version from the options above.
Key features and benefits:
4.3" color OLED display — the touch-sensitive, color screen allows for the display of dynamic QR codes for payments, advertising content, and individual personalization of selected screen elements.
Support for payment terminals — possibility of installing Payter Apollo and PAX IM30 terminals, enabling direct payment at the station.
Dynamic customer communication — operators can communicate with users in real-time via the station screen.
RFID authorization — secure access authorization using RFID cards or key fobs, enabling user control and logging of charging sessions.
Advanced safety features — available RCMB / RCDA / RCDB variants ensure full 24/7 protection.
Accessibility for people with disabilities — socket/plug located at a height of 96 cm in accordance with accessibility requirements and fully compliant with AFIR requirements.
Easy service — an additional inspection hatch at the bottom of the column and a diagnostic panel in service mode significantly simplify service work and diagnostics.
OCPP 1.6j connectivity — offline, WiFi, and LTE (GSM) support enables remote monitoring and management of the station from anywhere.
Technical data:
| Parameter | Vertica Pro Socket | Vertica Pro Cable |
|---|---|---|
| Charging power | 2 × 1.4 kW — 22 kW | 2 × 1.4 kW — 22 kW |
| Connector | 2 × Type 2 socket with lock | 2 × Type 2 plug |
| Cable (working length) | — | 6 m |
| Display | OLED 4.3", touch, color | OLED 4.3", touch, color |
| Authorization | RFID | RFID |
| Communication | offline / WiFi / LTE (GSM) | offline / WiFi / LTE (GSM) |
| Protocol | OCPP 1.6j | OCPP 1.6j |
| Energy meter | 3-phase, >99% accuracy | 3-phase, >99% accuracy |
| Protections | RCMB / RCDA / RCDB | RCMB / RCDA / RCDB |
| IP protection rating | IP54 | IP54 |
| IK protection rating | IK10 | IK10 |
| Operating temperature | from -25°C to +55°C | from -25°C to +55°C |
| Height | 1310 mm | 1310 mm |
| Terminal mounting | Payter Apollo and PAX IM30 | Payter Apollo and PAX IM30 |
| Mounting | Freestanding | Freestanding |
Pairs well with
Available! Ships within 1-2 business days
2-year warranty
Fast delivery and returns
Vertica Pro DUO Charging Station - Manual Configurator
Specification
Product description
This is the new generation of Enelion commercial EV charging stations — one of the few chargers in Europe equipped with a color OLED touchscreen with the ability to display dynamic QR codes for payments. Its slim, column-like design with two charging points makes it ideal for car parks, shopping centers, hotels, and residential areas.
The station is available in two configurations — with a Type 2 socket or a Type 2 cable — choose the appropriate version from the options above.
Key features and benefits:
4.3" color OLED display — the touch-sensitive, color screen allows for the display of dynamic QR codes for payments, advertising content, and individual personalization of selected screen elements.
Support for payment terminals — possibility of installing Payter Apollo and PAX IM30 terminals, enabling direct payment at the station.
Dynamic customer communication — operators can communicate with users in real-time via the station screen.
RFID authorization — secure access authorization using RFID cards or key fobs, enabling user control and logging of charging sessions.
Advanced safety features — available RCMB / RCDA / RCDB variants ensure full 24/7 protection.
Accessibility for people with disabilities — socket/plug located at a height of 96 cm in accordance with accessibility requirements and fully compliant with AFIR requirements.
Easy service — an additional inspection hatch at the bottom of the column and a diagnostic panel in service mode significantly simplify service work and diagnostics.
OCPP 1.6j connectivity — offline, WiFi, and LTE (GSM) support enables remote monitoring and management of the station from anywhere.
Technical data:
| Parameter | Vertica Pro Socket | Vertica Pro Cable |
|---|---|---|
| Charging power | 2 × 1.4 kW — 22 kW | 2 × 1.4 kW — 22 kW |
| Connector | 2 × Type 2 socket with lock | 2 × Type 2 plug |
| Cable (working length) | — | 6 m |
| Display | OLED 4.3", touch, color | OLED 4.3", touch, color |
| Authorization | RFID | RFID |
| Communication | offline / WiFi / LTE (GSM) | offline / WiFi / LTE (GSM) |
| Protocol | OCPP 1.6j | OCPP 1.6j |
| Energy meter | 3-phase, >99% accuracy | 3-phase, >99% accuracy |
| Protections | RCMB / RCDA / RCDB | RCMB / RCDA / RCDB |
| IP protection rating | IP54 | IP54 |
| IK protection rating | IK10 | IK10 |
| Operating temperature | from -25°C to +55°C | from -25°C to +55°C |
| Height | 1310 mm | 1310 mm |
| Terminal mounting | Payter Apollo and PAX IM30 | Payter Apollo and PAX IM30 |
| Mounting | Freestanding | Freestanding |
Station type
Specifies where and how the station is mounted and what its purpose is.
- Wallbox (wall-mounted) — mounted directly on the wall, ideal for a garage or parking space
- Freestanding post — mounted on a dedicated post, e.g., outside a building or in a parking lot
- Portable — mobile charger, can be plugged into a standard socket or a reinforced circuit
- Public station — designed for use by many users, e.g., in commercial car parks
Charging level
Determines the speed and type of electric vehicle charging.
- Level 1 (AC 230V) — slow charging via a standard household socket, up to 2.3 kW
- Level 2 (AC 400V) — faster home or business charging, from 3.6 kW to 22 kW — the most popular choice
- Level 3 (DC) — fast direct current charging from 50 kW upwards, charges a car to 80% in 20–40 minutes
Manufacturer
The brand that designed and manufactured the charging station.
- Arinea / Ultron — Polish manufacturer, DC and AC stations for businesses and public charging points
- Circontrol — Spanish manufacturer with 30 years of experience, home and commercial charging stations
- Besen — Premium manufacturer at a good price, home charging stations with a mobile application
- Wallbox — Leading European manufacturer of smart chargers with design and app
- Delta — Global manufacturer of DC fast charging stations for public use
Color
Charging station casing color.
- White — universal, fits any environment, the most popular choice for home use
- Black — elegant, modern look, recommended for garages and company parking lots
- Gray — neutral, discreet, often used in commercial spaces
Phase type
Specifies the electrical requirements of the installation and the maximum charging power.
- Single-phase (1×230V) — up to 7.4 kW, a standard outlet or dedicated circuit is sufficient, simple and inexpensive installation
- Three-phase 11 kW (3×16A) — faster charging, requires a three-phase connection, a good choice for home and business
- Three-phase 22 kW (3×32A) — maximum AC power, for heavily used vehicles and fleets
- DC (direct current) — from 50 kW, fastest charging, requires specialized installation
Key product features
Publiczne ładowanie
22 kW
ENELION
Czarny
Trójfazowy
Nowy
FAQ
— frequently asked questions
How to pass an electromobility audit?
An electromobility audit requires an assessment of a building's electrical installation. Our team will help you through the entire process — from technical assessment to selecting the appropriate charging station.
Can the housing community forbid me from installing a charging station?
The community cannot completely prohibit installation, but it may require consent. We assist in preparing documentation and communicating with the community.
How quickly can I charge my car with a Wallbox?
Charging time depends on the model of the charging station and battery capacity. A 7.4 kW station will charge most electric cars in 6–8 hours, while a 22 kW station can do it in as little as 2–3 hours.
Who can install a charging station?
Installation may only be carried out by a qualified electrician. Wallbox cooperates with certified installers throughout Poland – we can recommend a specialist in your area.
Does the charging station work in all weather conditions?
Yes – our stations are IP54/IP65 certified, which means full protection against rain, snow and dust. They operate flawlessly all year round.
